Unsulation boards PIR SOFT LE
INCREASING ENERGY EFFICIENCY REQUIREMENTS IN CONSTRUCTION PRESENT NEW CHALLENGES FOR INVESTORS AND CONTRACTORS.
To meet these growing demands, we offer the PIR SOFT LE insulation board, which is the key to achieving high thermal comfort while keeping heating costs low.
This board features an exceptional thermal conductivity coefficient of λ = 0.022 W/m•K, ensuring outstanding thermal insulation. The PIR SOFT LE board consists of two multilayer gas-tight laminate with an external layer of aluminum foil with a rigid PIR foam insulation core in between. The board is available in two versions: with straight edges (SE) or L-shaped edges on all four sides (LS).
Types of PIR SOFT LE
PIR SOFT LE LS
unsulation boards with L shaped edges on all four sides
PIR SOFT LE SE
unsulation boards with straight edges
MORE ABOUT PIR SOFT LE PANELS
ADVANTAGES OF PIR SOFT LE unsulation boards
▪ Excellent thermal insulation – λD = 0.022 W/m·K,
▪ Easy and quick installation,,
▪ Outstanding dimensional stability under changing operating conditions, preventing the formation of thermal bridges,
▪ Resistance to fungi and mold due to the closed-cell structure with gas-tight facings,,
▪ No biological threats – rodents do not penetrate the rigid PIR foam, ensuring long-term durability of the material without the need for replacement.
▪ Easy and quick installation,,
▪ Outstanding dimensional stability under changing operating conditions, preventing the formation of thermal bridges,
▪ Resistance to fungi and mold due to the closed-cell structure with gas-tight facings,,
▪ No biological threats – rodents do not penetrate the rigid PIR foam, ensuring long-term durability of the material without the need for replacement.
APPLICATION:
PIR SOFT LE insulation boards are an excellent material for use as insulation:
- of three-layer walls,
- of flat roofs,
- of shed roofs,
- of floors,
- of terraces.
ENERGY EFFICIENCY
They help to build a facility which is provided with an excellent thermal insulation and protected against loss of heat. With use of PIR SOFT LE unsulation boards it is possible to achieve the same insulating power with a lower thickness compared to mineral wool or expanded polystyrene foam, which proves that Paneltech PIR SOFT LE unsulation boards are the most efficient out of all commercially available insulating materials.
TABLE OF TECHNICAL PARAMETERS OF PIR SOFT LE PANELS
| Parameters | Value | |||||||||
| Thickness [mm] | 50* | 60 | 80 | 100 | 120 | 140 | 150* | 160 | 180 | 200 |
| Application | Insulation for flat roofs, shed roofs, three-layered walls, floors and terraces | |||||||||
| Type of milling | LS – L-shaped edges SE – straight edges |
|||||||||
| Coverage length [mm] | 2400 (SE) or 2385 (LS) | |||||||||
| Coverage width [mm] | 1200 (SE) or 1185 (LS) | |||||||||
| Coverage area [m2] | 2,88 (SE) or 2,83 (LS) | |||||||||
| Thermal resistance R [m2K/W] | 2,25 | 2,70 | 3,60 | 4,50 | 5,45 | 6,35 | 6,80 | 7,25 | 8,15 | 9,05 |
| Thermal conductivity coefficient of panel λD [W/m·K] | 0,022 (in accordance with EN 13165:2012+A2:2016 standard) | |||||||||
| Reaction to fire class | E | |||||||||
| Compressive strength (10% strain) [kPa] | ≥ 150 kPa (1,5 kg/cm2) | |||||||||
| Insolation core | Rigid PIR foam with a density of 32 ± 3 kg/m³ and a closed-cell structure | |||||||||
| Facing | LE: multilayer gas-tight laminate with an external aluminum foil coating | |||||||||
| Boards per pack | 10 | 8 | 6 | 5 | 4 | 3 | 3 | 3 | 2 | 2 |
| m2 perpack | 28,80 | 23,04 | 17,28 | 14,40 | 11,52 | 8,64 | 8,64 | 8,64 | 5,76 | 5,76 |
| Boards per pallet | 50 | 40 | 30 | 25 | 20 | 18 | 15 | 15 | 14 | 12 |
| m2 per pallet | 144,00 | 115,20 | 86,40 | 72,00 | 57,60 | 51,84 | 43,20 | 43,20 | 40,32 | 34,56 |
| m2 full load | 1584,00 | 1267,20 | 950,40 | 792,00 | 633,60 | 570,24 | 475,20 | 475,20 | 443,52 | 380,16 |
*For the SE board variant, please inquire about availability.
